Titanium Wire
Range from Dia0.03mm to Dia6.0mm,GR1 GR2 GR3 GR4 GR5 GR7 GR9 GR12 GR23
- Description
- Packaging & Delivery
Product Description
Item Name
Titanium Wire
Grade
Gr1, Gr2, Gr3, Gr4, Gr5(Ti-6AL-4V), Gr7, Gr9, Gr12, Gr23(Ti-6AL-4V Eli) etc.
ERTI-1, ERTI-2, ERTI-3, ERTI-4, ERTI-5, ERTI-7, ERTI -9 , ERTI -12, ERTI -23
Standard
ASTM B863, AWS A5.16,ASTM B348, ASTM F67, ASTM F136,
AMS4951, AMS4954, AMS4956
Specification
Dia0.03—Dia6.0mm
Type
Coil, Spool, Straight, Cut to length
Surface
Polished, Black oxide, Peeled, Pickling
Weight each
5—200KG for each coil or spool
Annual production capacity
200T/year
Sample
Small quantity samples are available before order
We offer
Cost control-manufacturing and exporting by ourselves;
Competitive price-without middleman;
Professional manufacturer to cut much purchasing costs down;
Quality guarantee- SGS, Mill Test Certificate, other test as ordered;
Samples are available before order
On-time delivery: 200 tons production capability yearly, large stock
Application
Titanium wires are widely used in the following industries:
Aerospace alloys and applications
Automotive applications
Medical implants
Surgical instruments
Architectural applications
Cladding to other materials
Optical frames
Bolts & Nuts
Piercing & Accessory
Netting in corrosion
3D Printing
Spherical Powder
| Grade | Ti | Chemical composition | |||||||||
| Major composition | residual elements (not more than) | ||||||||||
| Al | V | Sn | Mo | Pa | Fe | C | N | H | O | ||
| Gr1ELI | Bal | / | / | / | / | / | 0.10 | 0.03 | 0.012 | 0.008 | 0.10 |
| Gr1 | Bal | / | / | / | / | / | 0.20 | 0.08 | 0.03 | 0.015 | 0.18 |
| Gr2 | Bal | / | / | / | / | / | 0.30 | 0.08 | 0.03 | 0.015 | 0.25 |
| Gr3 | Bal | / | / | / | / | / | 0.30 | 0.08 | 0.05 | 0.015 | 0.35 |
| Gr4 | Bal | / | / | / | / | / | 0.50 | 0.08 | 0.05 | 0.015 | 0.40 |
| Gr5 | Bal | 5.5~6.75 | 3.5~4.5 | / | / | / | 0.30 | 0.08 | 0.05 | 0.015 | 0.20 |
| Gr5ELI | Bal | 5.5~6.5 | 3.5~4.5 | / | / | / | 0.25 | 0.08 | 0.03 | 0.0120 | 0.13 |
| Grade | Condition | Mechanical properties | |||
| Thickness
mm |
Tensile strength
Rm/Mpa |
Yield strength
Rp0.2/Mpa |
Elongation
A% |
||
| Gr1ELI | M | 0.3~25mm | >=200 | >=140 | >=30 |
| Gr1 | >=240 | >170 | >=25 | ||
| Gr2 | >=400 | >=275 | >=25 | ||
| Gr3 | >=500 | >=380 | >=20 | ||
| Gr4 | >=580 | >=485 | >=20 | ||
| Gr5 | 0.8~4.75 | >=925 | >=870 | >10 | |
| >4.75~25 | >=895 | >=830 | >=10 | ||
| Gr5ELI | 0.8~25 | >=860 | >=795 | >=10 | |
- Packaging Details: inner packaging: plastic bag packaged with supporting thing inside; outer packaging: Polywood Case or Wooden Case with strips as you request
- Delivery Detail: Within 5~15 days
